Видеокамера за наблюдение ST01 DVR MSD

Model Box/IR dome-ST01
Image Capture
Image Sensor-1/4" CMOS High Clear CMOS Sensor
Pixels-30 million Pixels resolution
Minimum illumination-0 Lux/F1.2 ( IR Leds on)
Lens-f=6mm, F=1.2, Infrared lens,
Image Stabilization Support
AUX
lighting-8-12 pcs 850nm IR leds, IR View Distance 5~10meters
lightness Control-LDR(light dependent resistor) Automatic Control,D/N functions
Video Processing
Resolutin VGA Mode(640*480)
Static real-time frame rate-Max.30 Frames/second
Continuous shooting speed-1 Frame/second
Character superposition-Support OSD Menu
System Configurations
ARM- High speed ARM CPU?Advanced DSP Processing and Software Control Technology
DSP-Adopt Vimicro DSP
Local Storage-Support Max 8G TF card
System Mechanism-With the Advanced Cutting-edge system mechanism, ensure TF Card File System for a long time to record without Error
Other Functions
Motion Detective-Passive Infrared Ray (PIR) Motion-detecting tech adopted
Storage Charater-Support hot-swapping, ensure reliable preservation of the video data when a sudden power failure occurred.
Storage Partern-Storage image automatic overwrite former image and Ensure the latest functions of image data
Storage Time-Storage Max.30 days,According to the Surveillanre Area.
Storage Port-External TF card slot/Built-in TF card slot
Time/Date Settings Rely on TF card relay, support the system time regulating
Physical Index
Weight-200g/160g
Dimensions-Box camera:100mm(Length)*51mm(Width)*58mm(Height)Dome camera:93mm(Diameter) * 80mm(Height)
Supply Powe-DC 12V 500mA
Power-<3W
Operation Temp. -20C~60C
Operation Humidity 10% ~ 80% No condensation
Browser
Surveillance Patern TV, Monitor
Client Software-Professional PC Player software
